Output1 PID1 minimum limiter setting screen
Initial value:0.0
Setting range: 0.0～99.9%
key Output lower limit value of output 1 PID1 is set up.
Note: At the time of STBY (RST) and scale over output,
limiter value is disregarded.
Output 1 PID1 maximum limiter setting screen
Initial value:100.0
Setting range: output limiter lower limiter values +0.1～100.0%
key Upper limit value of output 1 PID1 is set .
Output 1 PID2 proportional band (P) setting screen
Initial value:3.0%
Setting range: OFF, 0.1～ 999.9%
key Content is the same with output 1 PID1.
Output 1 PID2 integral-time (I) setting screen
Initial value: 120 seconds
Setting range: 0FF, 1～6000 seconds
key Contents is the same with output 1 PID1.
Output 1 PID2 derivative-time (D) setting screen
Initial value: 30 seconds
Setting range: 0FF, 1～ 3600 seconds
key
Contents is the same with output 1 PID1.
Output 1 PID2 manual reset setting screen
Initial value: 0.0
Setting range: －50.0～50.0%
key Contents is the same with output 1 PID1.
Output 1 PID2 differential gap setting screen
Initial value: 5
Setting range: 5～999 unit
key Contents is the same with output 1 PID1.
Output 1 PID2 minimum limiter setting screen
Initial value:0.0
Setting range:0.0～99.9％
key Contents is the same with output 1 PID1.
Output 1 PID2 maximum limiter setting screen
Initial value: 100.00
Setting range: output limiter lower limit value +0.1～100.0%
key Contents is the same with output 1 PID1.
Output 1 PID3 proportional band (P) setting screen
Initial value: 3.0%
Setting range:OFF, 0.1～ 999.9%
key
Contents is the same with output 1 PID1.
Output 1 PID3 integral-time (I) setting screen
Initial value: 120 seconds
Setting range: 0FF, 1～ 6000 seconds
key
Contents is the same with output 1 PID1.
Output 1 PID3 derivative time (D) setting screen
Initial value: 30 seconds
Setting range: 0FF, 1～3600 seconds
key
Contents is the same with output 1 PID1.
Output 1 PID3 manual reset setting screen
Initial value:0.0
Setting range:－50.0～50.0%
key Contents is the same with output 1 PID1.
Output 1 PID3 differential gap setting screen
Initial value:5
Setting range:1～999 unit
key Contents is the same with output 1 PID1.
Output 1 PID3 minimum limiter setting screen
Initial value: 0.0
Setting range: 0.0～99.9％
key Contents is the same with output 1 PID1.
Output 1 PID3 maximum limiter setting screen
Initial value: 100.0
Setting range: output limiter lower limit values +0.1～100.0%
key Contents is the same with output 1 PID1.
Output 1 soft starting time setting screen
Initial value: OFF
Setting range:OFF, 0.5～120.0 seconds (setting resolution 0.5 second)
This is the function that eases change of output at the time of a power-on and startup.
key Does not function at the time of OFF setup.
Output 1 proportional periodic time setting screen
Initial value: Contact output 30.0 seconds
Voltage pulse output 3.0 seconds
key Setting range: 0.5～120.0 seconds (setting resolution 0.5 second)
Proportional periodic time of output 1 is set.
Not displayed when output 1 is current.
Output 1 characteristics setting screen
Initial value:
Setting range:、
key Characteristics of control output is chosenfrom (heating characteristics)
and (cooling characteristics)
Return to mode 3 lead screen
(7) Mode 4 screens
Mode 4screens is the setup screens of output 2 option. Not displayed when option is not added.
Mode 4 lead screen
No setup
Press key , then it shifts to the first setting screen,output 2 proportional band 1
key setting screen.
On this screen, PID1～3 related items that can be used in output 2,
soft start of output 2,and proportional period output characteristics are set.
Output 2 PID1 proportional band (P) setting screen
Initial value:3.0%
Setting range:OFF, 0.1～ 999.9%
key
Contents is the same with output 1 PID1.
Output 2 PID1 integral-time (I) setting screen
Initial value: 120 seconds
Setting range: 0FF, 1～ 6000 seconds
key Contents is the same with output 1 PID1.
Output 2 PID1 derivative-time (D) setting screen
Initial value: 30 seconds
Setting range: 0FF, 1～3600 seconds
key Contents is the same with output 1 PID1.
Output 2 PID1 dead-band setting screen
Initial value:0
Setting range: －1999～5000 unit
key
Output 2's operation zone to output 1 is set with dead- band.
Output 2 PID1 differential-gap setting screen
Initial value:5
Setting range: 1～999 unit
key Contents is the same with output 1 PID1.
Output 2 PID1 minimum limiter setting screen
Initial value: 0.0
Setting range: 0.0～99.9％
key Contents is the same with output 1 PID1.
To Next Page
