5. Description of screens
5. Description of screens5. Description of screens
5. Description of screens
5
55
5-
--
-1. How to move to another screen
1. How to move to another screen1. How to move to another screen
1. How to move to another screen
Basic Screen
3 seconds (constant value control) lead screen of setting screens or (Program control) lead screen of setting screens
3 seconds
Press the key for 3 seconds on a basic screen, then it shifts to the lead screen of (constant value control) setting screens, or to the lead screen of (program control) setting screens.
Press the key for 3 seconds on or the lead screen of setting screens, then it shifts to the basic screen..The shift is also possible when the program option is added and is chosen on the
operation mode 2 screen. The shift is possible when the program option is added and is chosen on the operation mode 2screen.
Basic Screens
Mode 1 ～ 9 screens
Basic Screen
Mode 1 lead screen Mode 2 lead screen Mode 9 lead screen
three seconds
three seconds
Operation mode 1 key lock PV offset correction
Every time you press the key on a basic screen, it shifts to each screen of the basic screens.
Press the key for 3 seconds on a basic screen, then it shifts to the lead screen of mode 1 screens.
Press the key on the lead screen of mode 1 screens , then it further advances to mode 2, and mode 3. (Notes: If no corresponding option is found, the mode 4 - 9 is skipped)
Press the key on the lead screen of mode 1 screens , then it further advances to mode 9, and mode 8. (Notes: If no corresponding option is found, the mode 4 - 9 is skipped)
Press the key for 3 seconds on the lead screen of mode 1～ 9 screens, then it shifts to the basic screen.
Press the key on the lead screen of mode 1～ 9 screens, then it shifts to the first setting screen of each screens.
Press the key on the the first setting screen of each screens, then it shifts to the next screen. Every time you press the key, it shifts to the next setting screen.
5
55
5-
--
-2. Setting Method
2. Setting Method2. Setting Method
2. Setting Method
To change settings, display an appropriate screen and change the setting (value or function) by pressing or key.
On the output monitor screen of basic screens, you can change the control output from "Automatic" to "manual" ,and save its change of setting. Display the output monitor screen, and then press key for
three seconds to shift from Automatic to Manual. Then by pressing or key, you can adjust to the desirable output value. In this case, no need to press key in order to determine the change of setting.
Press key for three seconds as well to shift back to Automatic. Excluding when a keylock is OFF, Automatic⇔Manual switchover does not work while STBY<RST> and AT are in operation.
In the case of two-output type, the switchover between automatic and manual is operatable through output 1 and output 2. The setting is altered simultaneously.
Output monitor Output monitor Output monitor
three seconds
or
Automatic screen RUN lamp lights up Manual screen RUN lamp blinks Manual screen RUN lamp blinks
5
55
5-
--
-3. Power
3. Power3. Power
3. Power-
--
-on and initial screen display
on and initial screen displayon and initial screen display
on and initial screen display
At power-on, the display section shows each screen of initial screens for one second , then moves on to the basic screen.
《Power-on》
All LED light up Input type Upper limit & lower limit of measuring range Out 1 type ※
※※
※ Out 2 type Basic screen
：Contact ：Voltage pulse ：Current ※
※※
※Output 2 Displays only optional addition.
5
55
5-
--
-4. Explanation of each scre
4. Explanation of each scre4. Explanation of each scre
4. Explanation of each scre
(1) Basic Screens
Basic Screen
Executed SV initial value：Sensor input 0
Linear input Lower limit of scaring range
Setting range：Sensor input Within measuring range
key Linear input With in scaring range
Within SV limiter besides
Targeted value (PV) is displayed on the upper row as four-digit ,and target d
value (SV) is displayed on the lower row also as four-digit. (Notes:hereinafter,
measured value and targeted value are referred to as"PV" and "SV")
At the time of FIX, execution SV is displayed and change of setting is possible.
PROG's SV is just displayed ,and change of setting is impossible.
Action Mode 1 screen
Initial value:：(stanby)（Initial value at the time of constant value control）
（reset）(Initial value at the time of program control)
Setting range:：（） Control stop [Output OFF (0%)] operation
key conduct of control operation
Choose (RUN) by key. Decide by key, then Monitor LED's RUN lights up to
start control operation.
Choose （）by key、Decide by key, hen Monitor LED's RUN lights off
and becomes control stop [Output OFF (0%)] conducting.
Priority is given to DI when RUN is allotted to external control input. DI. Key operation cannot be
performed unless allotment is canceled.
When measuring range, a unit, scaling, and output characteristics are changed it is initialized and
() is displayed.
Press key for 3 seconds, then it shifts to Action mode2 screen,when the program control
option is added on this screen, FIX (constant value control) ←→PROG (program control)
switchover is possible choose.
Choose a program,then Monitor LED's PRG lights up.
Action mode1 screen Action mode2 screen
three seconds
three seconds
three seconds PRG LED lights up
Press key for 3 seconds on Action mode2 screen, then it returns to Action mode1 screen.
Action mode2 screen is not displayed without a program option.
When PROG is allotted to DI, DI is given priority. Key operation cannot be performed unless
allotment is canceled.
Press key on Action mode1 screen, then it shifts to output 1 monitoring screen.
To Next Page
