Output 1 monitoring screen
manual output setting range: :0.0-100.0% (within output limiter)
At the time of automatic output,monitor display only.
key Refer to Item 5-2 about automatic ⇔ manual switchover,and setting method at the
time of manual operation.
A manual output is canceled when an operation mode is made into ().
When a power source is intercepted and re-switched on, it returns to the condition just before
intercepting.
When is allotted to DI, DI is given priority. Automatic ma ⇔ manual switchover
is not performed with key operation,and only the output value at the time of manual
operation can be changed.
Output 2 monitoring screen
Contents are the same with that of an output 1.
key Output 2 monitoring screen displays only when output 2 option is added.
CT1 current monitoring-screen
Current display range: 0.0-55.0A
Displays at the time of CT input option addition, and the current value detected by CT
sensor is displayed.
key Current value is displayed.
CT2 current monitoring screen
Contents are the same with that of an output 1.
key
Monitoring screen of step's remaining time period
:
::
: Displays while program is in operation if program option is added.
key Step № in progress and remaining time are displayed by turns.
(In ∞ setting, step № and are displayed by turns)
A remaining time and an elapsed time is switchable by pressing the key for 3 seconds.
(Switchover is interlocked with the number of times of next screen pattern.)
Decimal point of the minimum digit lights up in displaying elapsed time,
This screen is not displayed without a program option.Not displayed in the state of
program ＲST and FIX neither.
Monitoring screen for the remaining repeating time of pattern
Being displayed while program is in operation, when the program option is added,
On-going step № and the remaining repeating time of pattern are displayed by turns.
key (In ∞ setting, step № and are displayed by turns)
A remaining time and actually performed times are switchable by pressing the key
for 3 seconds. (Switchover is interlocked with front screen step time.)
The decimal point of the minimum digit lights up when actually performed times being displayed.
This screen is not displayed without a program option.Not displayed in the state of
Program ＲST and FIX neither.
PID № monitoring screen
Chosen PID № is displayed when FIX is in operation.
PID № chosen at each step and on-going step № are displayed by turns when PROG
key is in operation.
PID № of output 1 is displayed in the first digital, and PID № of output 2 is displayed in
the third digital. The third digital is shown as when there is no output 2 option.
This screen is not displayed in the state of STBY (RST).
HOLD (temporary stopping) execution screen
Initial value:：
Setting range:：、
While HOLD is executed, on the basic screen,SV value and is displayed by turns . If
switched while PROG is in operation , the operation temporary stops with
as of then step time and SV value. While HOLD is in execution , SV value and
is displayed by turns in basic screen.、
HOLD is used in order to perform AT in the middle of an inclination step or to compensate the
insufficient time of flat step.
Controls is performed with SV value at the time of stopping,while HOLD is in execution
HOLD is canceled if is chosen while HOLD is in execution. The remaining time
of the step is performed based on a program.
(skip)is unable to perform while HOLD is in execution.
When is allotted to DI, DI is given priority.
Execution and release of HOLD with key operation is unable to perform.
This screen is not displayed without a program option.Not displayed in the state of program
and FIX neither.
SKIP (skip) execution screen
Initial value:：
Setting range:：、
SKIP (skip) is the function that makes to end the on-going step compulsorily, and is to shift to
the following step. The next step starts instantly, if performed.
When SKIP is continuously performed, about 1 second interval is required from execution to the
next one.
Even if SKIP is allotted to DI, execution is able to perform with DI and key operation.
key SKIP cannot be performed while HOLD is in operation.
This screen is not displayed without a program option. Not displayed in the state of
program
and FIX neither.
AT (Auto Tuning) execution screen
Initial value:：
Setting range:：、
key
AT is performed by ON selection ,and canceled by OFF selection.
Not displayed at the time of STBY(RST), a manual output, and P(proportional band) =OFF.
Except in the setting of keylock OFF, AT is unable to perform in scale over.
(At the time of DI allotment,execution of AT by DI can be performed .)
Even in such a case,halfway release is performed on this screen.
Release of AT, STBY(RST), EV operating point, setting of keylock, and mode 5 ～
9screen are operateable with key.
Except in th setting of AT normal end, execution of AT is canceled compulsorily at the time
of STBY(RST) selection and AT release setup.
EV1 (event 1) operating-point setting screen
Initial value: upper limit absolute value measuring range Scaling upper limit
lower limit absolute value measuring range Scaling lower limit
upper limit deviation
key lower limit deviation
within deviation
outside deviation
CT1 or CT2
guarantee
Setting range: upper limit absolute value within measuring range within scaling limit
lower limit absolute value within measuring range within scaling limit
upper limit deviation ～ unit
lower limit deviation ～ unit
within upper-lower limit deviation ～ unit
outside upper-lower limit deviation ～ unit
CT1 or CT2 ～Ａ
The operating point of the alarm type allotted to EV1 is set up.
No option, No display when , , , , ・ , ,
, , , and are allotted to EV1.
The operation mode of each deviation alarm is .
Effective at the time of automatic output.
Each deviation alarm serves as PV’s deviation to Execution SV.
Event operation other than each deviation alarm is always effective.
EV2 (event 2) operating-point setting screen
Initial value,setting range, contents are the same with EV1
key
EV3 (event 3) operating-point setting screen
Initial value,setting range, contents are the same with EV1
key
When EV3 option is added, event 3 is displayed as the same contents with EV 1 and 2,
irrespective of EV 1 and 2.
To Next Page
