Latching release screen
Initial value:：
Setting range:： release EV1
release EV2
key release EV3
release all EVs at a time
On the latching setting screen of each EV mode, № and which chose
are displayed. If latching is ,once EV is outputted, EV output state is maintained even
if EV is in the state of OFF. When EV is in a latching state, decimal point of the minimum
digit blinks, and it shows that release of EV is possible. If key is pressed, EV is released
and a decimal point lights off.
However, release is impossible when a state is in EV power range.
Return to basic screen
(2) FIX (constant value control) setting screens
At the time of no program option and with program option and is chosen on Action
mode2 screen of basic screens,lead screen of FIX setting screens is displayed when key is
pressed for 3 seconds.
If key is pressed for 3 seconds on lead screen, it returns to basic screen.
basic screen lead screen of FIX setting
three seconds
three seconds
FIX lead screen
No setting on this screen.
key Press key , then it shifts to the first setting screen SV1 setting screen.
SV1 setting screen
Initial value : At the time of sensor input 0
linear input time scaling lower limit
Setting range: sensor input time within measuring range
key linear input time within scaling range
Moreover, within limit of SV limiter.
When SV1 is Execution SV,being reflected in basic screen.
Being initialized when measuring range, unit, and scaling are changed.
SV1 output1 PID No. setting screen
Initial value : 1
Setting range:1, 2, 3
key When SV1 is Execution SV,PID№ that will be used for control of output 1
is chosen from 1～3.
SV1 output2 PID No. setting screen
Initial value:1
Setting range:1,2,3
key When SV1 is Execution SV,PID№ that will be used for control of output 2 is
chosen from 1～3.
Displayed when output 2 option is added.
SV2 setting screen
Initial value: same with SV1
Setting range: same with SV1
key
Displayed when SV2 is allotted to DI.When terminal of allotted DI short-circuits, it becomes
Execution SV.
When SV2 is Execution SV, it is reflected in basic screen.
Being initialized when measuring range, unit, and scaling are changed.
SV2 output 1 PIDNo. setting screen
Initial value:1
Setting range:1,2,3
Displayed when SV2 is allotted to DI.
key When SV2 is Execution SV,PID№ that will be used for control of output 1 is
chosen from 1～3.
SV2 output 2 PIDNo. setting screen
Initial value:1
Setting range:1,2,3
key Displayed when SV2 is allotted to DI.
When SV2 is Execution SV,PID№ that will be used for control of output 2 is
chosen from 1～3.
Displayed when output 2 option is added.
SV3 setting screen
Initial value: same with SV1
Setting range: same with SV1
key Displayed when SV3 is allotted to DI.When terminal of allotted DI short-circuits,
it becomes Execution SV.
When SV3 is Execution SV, it is reflected in basic screen.
Being initialized when measuring range, unit, and scaling are changed.
SV3 output 1 PIDNo. setting screen
Initial value:1
Setting range:1,2,3
key Displayed when SV3 is allotted to DI..
When SV3 is Execution SV,PID№ that will be used for control of output 1 is
chosen from 1～3.
SV3 output 2 PIDNo. setting screen
Initial value:1
Setting range:1,2,3
key Displayed when SV3 is allotted to DI..
When SV3 is Execution SV,PID№ that will be used for control of output 2 is
chosen from 1～3.
Displayed when output 2 option is added.
SV4 setting screen
Initial value: same with SV1
Setting range: same with SV1
key Displayed when SV4 is allotted to DI..
When terminal of allotted DI short-circuits, it becomes Execution SV.
When SV4 is Execution SV, it is reflected in basic screen.
Being initialized when measuring range, unit, and scaling are changed.
SV4 output 1 PIDNo. setting screen
Initial value:1
Setting range:1,2.3
key Displayed when SV4 is allotted to DI..
When SV4 is Execution SV,PID№ that will be used for control of output 1 is
chosen from 1～3.
SV4 output 2 PIDNo. setting screen
Initial value:1
Setting range:1,2,3
key Displayed when SV4 is allotted to DI..
When SV4 is Execution SV,PID№ that will be used for control of output 2 is
chosen from 1～3.
Displayed when output 2 option is added.
Return to FIX lead screen
(3) PROG (program control) setting screens
Press key for 3 seconds, lead screen of the PROG setting screens is displayed,When program
option is added and is chosen on Action mode2 screen of basic screens.
If key is pressed for 3 seconds on lead screen, it returns to basic screen.
Basic screen lead screen of the PROG setting screens
three seconds
three seconds
Press Key for 1second it will move to Program pattern 2 screen, and Press key 1second
It will move to program pattern 1,2, 4,
The number of setting in the program pattern screen can be changed 1-4 to the number of program
pattern.(1=pattern 1,2= pattern 1 & 2, 4= pattaern 1 to 4)
Only the pattern you did program pattern setting screen will be indicated.
1second 1second 1second 1second
Please refer explanation
of program sequence
To Next Page
