Shini SHD-200 - 22. Specification

73(111)
22. Specification
SHD 12 25 50 75 100 150 200 300 400 500 600 800 1000
Ver. B A A A A A A A A A A B B
Heater Power
(kW)
2.2
/ 3*
3
/ 3.3*
3.9
/ 4.2*
4.2
/ 4.8*
6
/ 6.6*
6.6
/ 7.2*
12
/ 15*
15 18 19.5 21 24 32
Blower Power
(50 kW)
0.05 0.12 0.12 0.12 0.12 0.12 0.18 0.18 0.18 0.18 0.55 1.1 1.1
Loading
Capacity (kg)
12 25 50 75 100 150 200 300 400 500 600 800 1000
H(mm) 790 1015 1145 1240 1340 1580 1580 1980 2170 2350 2570 2760 3060
H1(mm) 690 925 1045 1150 1340 1605 1332 1432 1900 1900 2075 2300 2530
H2(mm) 317 410 380 475 470 470 550 550 838 838 838 1010 1010
H3(mm) 370 460 520 620 725 970 975 1220 1220 1400 1545 540 540
H4(mm) 106 194 206 208 233 233 184 184 334 334 334 1550 1845
H5(mm) 115 150 150 150 158 158 158 158 283 283 283 283 283
W(mm) 660 725 840 900 955 955 1230 1230 1365 1365 1365 1420 1420
D(mm) 360 405 490 550 605 605 770 770 915 915 950 600 600
D1(mm) 130 158 158 158 238 238 238 238 345 345 345 345 345
W1(mm) 130 148 148 148 238 238 238 238 345 345 345 345 345
ΦA(mm) 325 385 470 530 595 595 750 750 910 910 910 960 960
ΦB(mm) 55 55 55 55 90 90 90 90 105 105 105 105 105
Weight (kg) 35 40 45 55 70 75 100 120 165 170 240 280 300
Note: 1) Install 24hr timer, add "T" at the back of the model.SHD-100 and models above standard equipped
with the timer.
2) Additional note of "M" will be added to SHD-300 and below models, the bases of which are changed to
be magnetic bases.
3) Change into double insulated layer, add "I" at the back of the model
4) Upon request, it can be built to comply with worldwide electrical safety standards .
5) Above loading capacity is based on pellet material of 0.65kg/L in bulk density and 3~5mm in diameter.
6) “*”Stands for high-temp.model, add "H" at the end of model code.
7) Power: 3Φ, 230/400/460/575VAC, 50/60Hz.
