24.7 Bill of Electrical Parts (SHD-12~1000 400V)
24.7.1 Bill of Electrical Parts (SHD-12) (400V)
No. Symbol
Parts Name Seecifications Parts No.
1 Q1 Circuit breaker* 10A 3P 400V 50/60Hz YE40301003000
2 - Excitation breaker 230V 50/60Hz YE40023560000
3 K1 Contactor* 220V 50/60Hz YE00601521000
4 K2 Contactor* 220V 50/60Hz YE00601621000
5 K3 Temp.controller* 230V 50/60Hz YE85019900000
6 K4 24Hours timer 230V 50/60Hz YE86002400000
7 FU1 Fuse base** 2P YE41032200000
8 - Fuse** 1A YE46001000100
9 FU2 Fuse** 6*30mm 2A 250V YE41001000000
10 T Transformer* 300mA YE70402300700
11 S1 S2 Alternative switch 4P (WH) YE10210400000
12 S3 Alternative switch 6P (WH) YE10220600000
13 S4 Overheat protector* 15A BE85013000050
14 S5 Thermocouple* - BE90555800050
15 X1 Terminal board 2.5mm² YE61250040000
12 M1 Blower* 400V 50Hz 0.05kW BM40001500550
13 EH1 Pipe heater ** 400V 50Hz 2.2kW BH70120300150
24.7.2 Bill of Electrical Parts (SHD-25) (400V)
No. Symbol
Parts Name Seecifications Parts No.
1 Q1 Circuit breaker* 10A 3P 400V 50/60Hz YE40301003000
2 - Excitation breaker 230V 50/60Hz YE40023560000
3 K1 Contactor* 220V 50/60Hz YE00601521000
4 K2 Contactor* 220V 50/60Hz YE00601621000
5 K3 Temp. controller* 230V 50/60Hz YE85019900000
6 K4 24Hours timer 230V 50/60Hz YE86002400000
7 FU1 Fuse base** 2P YE41032200000
8 - Fuse** 1A YE46001000100
9 FU2 Fuse** 6*30mm 2A 250V YE41001000000
10 T Transformer 310mA YE70402300700
11 S1 S2 Alternative switch 4P (WH) YE10210400000
12 S3 Alternative switch 6P (WH) YE10220600000
13 S5 Thermocouple* - BE90555800050
12 M1 Blower* 400V 50Hz 0.12kW BM40002500350
13 EH1 Pipe heater** 400V 50Hz 3.0kW BH70250300150
* means possible broken parts.
** means easy broken part. and spare backup is suggested.
Please confirm the version of manual before placing the purchase order to guarantee that the item number
of the spare part is in accordance with the real object.
