95(111)
24.7.7 Bill of Electrical Parts (SHD-200) (400V)
No. Symbol
Parts Name Seecifications Parts No.
1 Q1 Circuit breaker* 25A 3P 400V 50/60Hz YE40302503000
2 - Excitation breaker 230V 50/60Hz YE40023560000
3 K1 Contactor* 220V 50/60Hz YE00601521000
4 K2 Contactor* 220V 50/60Hz YE00602622000
5 K3 Temp. controller* 230V 50/60Hz YE85019900000
6 K4 24Hours timer 230V 50/60Hz YE86002400000
7 FU1 Fuse base** 2P YE41032200000
8 - Fuse** 1A YE46001000100
9 FU2 Fuse** 6*30mm 2A 250V YE41001000000
10 T Transformer* 300mA YE70402300700
11 S1 S2 Alternative switch 4P (WH) YE10210400000
12 S3 Alternative switch 6P (WH) YE10220600000
13 S4 Overheat protector* 15A BE85013000050
14 S5 Thermocouple* - BE90510000050
15 X1 Terminal board 2.5mm² YE61250040000
16 M1 Blower* 400V 50Hz 0.18kW BM40005000150
17 EH1 Pipe heater** 400V 50Hz 12kW BH70203800050
24.7.8 Bill of Electrical Parts (SHD-300) (400V)
No. Symbol
Parts Name Seecifications Parts No.
1 Q1 Circuit breaker* 32A 3P 400V 50/60Hz YE40303203000
2 - Excitation breaker 230V 50/60Hz YE40023560000
3 K1 Contactor* 220V 50/60Hz YE00601521000
4 K2 Contactor* 220V 50/60Hz YE00602722000
5 K3 Temp. controller* 230V 50/60Hz YE85019900000
6 K4 24Hours timer 230V 50/60Hz YE86002400000
7 FU1 Fuse base** 2P YE41032200000
8 - Fuse** 1A YE46001000100
9 FU2 Fuse** 6*30mm 2A 250V YE41001000000
10 T Transformer* 300mA YE70402300700
11 S1 S2 Alternative switch 4P (WH) YE10210400000
12 S3 Alternative switch 6P (WH) YE10220600000
13 S4 Overheat protector* 15 BE85013000050
14 S5 Thermocouple* - BE90510000050
15 X1 Terminal board 2.5mm² YE61250040000
16 M1 Blower* 400V 50Hz 0.18kW BM40005000150
17 EH1 Pipe heater** 400V 50Hz 15kW BH70303800050
* means possible broken parts. ** means easy broken part. and spare backup is suggested.
Please confirm the version of manual before placing the purchase order to guarantee that the item number
of the spare part is in accordance with the real object.
