Shini SHD-EB Series User Manual

10(49)
1.3 Technical Specifications
1.3.1 External Dimensions
Picture 1-1: External Dimensions
1.3.2 Specification
Table 1-1: Specification
Mode SHD-25-EB SHD-50-EB SHD-100-EB SHD-200-EB
Heater(kW) 3/3.3* 3.9/4.2* 6/6.6* 12/15*
Blower(kW) 0.12 0.12 0.12 0.18
Loading
Capacity (kg)
25 50 100 200
H(mm) 1015 1145 1340 1332
H1(mm) 925 1045 1340 1332
H2(mm) 410 380 470 550
H3(mm) 460 520 725 975
H4(mm) 194 206 233 184
H5(mm) 150 150 158 158
W(mm) 725 840 955 1230
D(mm) 405 490 605 770
D1(mm) 158 158 238 238
W1(mm) 148 148 238 238
ФA (mm) 385 470 595 750
ФB (mm) 55 55 90 90
Net weight (kg) 40 45 70 100
Note: 1) Above loading capacity is based on pellet material of 0.65kg/L in bulk density and 3~5mmin diameter.
2) “*”Option for high-temperature model, and the max. temperature is 180°C.
3) Power: 3Φ, 230/400/460/575VAC, 50/60Hz.
