Shining KF-34GW - 9000-12000 Btu

9
GREEN SIGN
21 22 23 24 25 26 27 28 29 30
Air lter
Air outlet
Horizontal grill
Vertical grill
（by hand）
180180
Hole center ofφ65Hole center ofφ65
RulerRuler
unit（mm）
9000-12000Btu
810
280
185
Indoor unit
Name of parts
Installation dimension
Front cover
Air inlet
Temp.indicator lights
(Room temp & setting temp)
Place for opening the cover
Power wire
Temporary switch
Power indicator light
on when operation
(blinking when defrost & fault)
Signal receiver
Dimensions
