Shining KF-34GW - 18000 Btu

10
70
50
70
50
Hole center ofφ65Hole center ofφ65
unit（mm）
Air inlet
Air lter
Air outlet
Horizontal grill
Vertical grill
（by hand）
GREEN POWER
21 22 23 24 25 26 27 28 29 30
power
1000
325
190
Name of parts
Installation dimension
Front cover
Temp.indicator lights
(Room temp & setting temp)
Place for opening the cover
Power indicator light
on when operation
(blinking when defrost & fault)
Power wire
Temporary switch
Signal receiver
Indoor unit
Dimensions
18000Btu
