Shining KF-34GW - Outdoor Unit Physical Characteristics

13
TOO WARM TOO COOL
ON/OFF
HR
MIN
AM CLOCK PM
We show you all signal in led.
Wall split cooling only models 7000Btu,9000Btu,12000Btu,18000Btu,24000Btu。
Dual split cooling only models 7000×2Btu，9000×2Btu。
Inverter cooling only models 9000Btu，12000Btu。
1
2
3
4
Signal transmitting section
Operation display
Power on/o button
Operation select button
Remote controller
Indoor unit fan speed control,button
Sleep mode set button
Timer on button
Time set button
Clock set button
Temp adjustment buttons
Horizontal vane control button
Swing button
Timer o button
Reset button
Remove the back lid
