Shire Cubby - Roller Catch Attachment; Securing Walls to Floor

25

GB‐IEAachthe"RollercatchRC"catchtothedoorandthebodytothedoorframe.

26
GB-IE Fix the walls to the floor with 2 x 60mm screws per panel
Screw
(60mm) x8
24
6mm
Door catch block
(34s-100)x01
Screw
(25mm) x04
Roller catch
(RC)X01
Screw
(60mm) x2
Door
(34s-100)x01

34mm
34mm
Door
34S‐100
