Shire Pixie - Step 09: Gable Panel Installation; Step 10: Safety Vent Installation

GB-IE Place the Back Gable "A2957-1 " panel level with the framework and fix to the panel below .
Repeat with the front gable.”A2957”
10
09
60mm Screw
(A0035) x08
Back Gable
(A2957-1) x01
GB-IE Push the vents into the holes in the back gable panel.
Front Gable
(A2957) x01
Safety vent
(A0476) x01
5mm
20
