No. Part No. Part Name Q’ty Remark
1 1071990039 Grille 1
Optional
2 1080320105 Top Cover 1
3 1110060953 Condenser 1
4 1080050004 Outdoor Motor Supporter 1
5 1170040058 Outdoor Motor 1
6 1070030051AA Propeller Fan 1
7 1080050001 Left Grille Suppoeter 1
8 1080320113 Front Plate 1
9 1080320112 Fan Guard 1
10 1100110016 Compressor And It Accessories 1
11 1120110016 4-way Valve 1
12 1120351014 4-way Valve Assembly 1
13 1210320103 Base 1
14 1080050002 Right Plate 1
15 1120120021 Two-way Valve 1
16 1080050003 Valve Supporter 1
17 1121990040 Three-way Valve 1
18 1070350971 Electrical Box Cover 1
19 1070040001
Cable Clamp(φ6)
1
20 1070040003
Cable Clamp(φ8)
1
21 1170500131 Terminal 1
22 1170100010 Fan Motor Capacitor 1
23 1170100003 Compressor Capacitor 1
24 1080010006 Capacitor Strip 1
25 1080020001 Electrical Parts Box 1
26 1120351011 Capillary Assembly 1
27 1174561802 Outdoor Sensor 1
28 1190030010 Base Carton 1
29 1190070001 Cabinet Carton 1
30 1151990014 Base Foaming 1
31 1190070695 Cover Forming 1
Outdoor Unit- SRH-I124BE
Air Conditioner Service Manual
Not shown in the Explosion view.
