No. Part No. Part Name Q’ty Remark
1 1071990040 Grille 1
Optional
2 1080050011 Top Cover 1
3 1110060851 Condenser 1
4 1080050004 Outdoor Motor Supporter 1
5 1170040059 Outdoor Motor 1
6 1070030038AA Propeller Fan 1
7 1080050001 Left Grille Supporter 1
8 1080050009 Front Plate 1
9 1080320112 Fan Guard 1
10 1100020033 Compressor And It Accessories 1
11 1120500226 4-way Valve 1
12 1120501359 4-way Valve Assembly 1
13 1210500106 Base 1
14 1080050002 Right Plate 1
15 1120120021 Two-way Valve 1
16 1080050003 Valve Supporter 1
17 1120130032 Three-way Valve 1
18 1070350971 Electrical Box Cover 1
19 1070040001
Cable Clamp(φ6)
1
20 1070040003
Cable Clamp(φ8)
1
21 1170500131 Terminal 1
22 1170100027 Fan Motor Capacitor 1
23 1170100025 Compressor Capacitor 1
24 1080010006 Capacitor Strip 1
25 1081990010 Electrical Parts Box 1
26 1120501358 Capillary Assembly 1
27 1081990316 Partition plate 1
28 1174561802 Outdoor sensor 1
29 1191990181 Base Carton 1
30 1190040087LH Cabinet Carton 1
31 1150300003 Base Foaming 1
32 211301929 Cover Forming 1
Outdoor Unit- SRH-I184BE
Air Conditioner Service Manual
Not shown in the Explosion view.
To Next Page
