SHOTO SDA-10 - Technical Specifications and Environmental Requirements; Product types and technical parameters

5
(4) In order to satisfy Telecom Operator’s new demands on the
power-supply system, developed the integrative backup battery
module solution based on LFP battery, BMS, DC switch power
module or ups (uninterrupted power system).
(5) Higher gravimetric specific energy, during installing, there is no
extra demand for space and bearing compared with VRLA battery,
greatly reducing the cost of the area rented.
(6) Good temperature characteristics : working environment
temperature can reach -20～+60℃(recommended temperature：+15～
+35℃), which greatly reduces power consumption cost.
(7) LFP battery has excellent rate discharge performance, which
enables LFP battery with small capacity to meet large current
discharge requirements.
(8) Flexible allocation: muti-LFP battery modules in parallel, make
large capacity LFP battery module become true, not only enhance the
output power of the system, but also prolong the backup time of the
battery module.
4. Product types and technical parameters
Table 4-1 48V series of product specifications and models
Model
Nominal
voltage
(DC V)
Nominal
capacity
(Ah)
Maximum
load
current（A）
Dimension (mm)
（width×depth×height）
Weight
(kg)
Remarks
48V100Ah
48
100
50
442×400×176（4U）
45
parallel system
48V100Ah
48
100
50
442×480×176（4U）
45
parallel system
48V150Ah
48
150
100
442×480×266 (6U)
65
parallel system
48V200Ah
48
200
100
442×480×354 (8U)
86
parallel system
