6
Note: size deviation is ±2mm，Weight deviation is ±2Kg.
Remarks ：The size of the table above is only for the battery module,
excluding cabinet, rack, rain box, etc. In order to ensure the safety,
reliability and stability of high-capacity LFP battery parallel system,
the expected capacity must be consistent with the actual capacity.
5. Environmental requirements
Ambient temperature：-20～+60℃（suggested temperature：
+15~+35℃）;
Storage temperature：-40～+70℃（suggested temperature：
+15~+35℃）;
Relative humidity：5%～85%RH;
Hight：not exceeding 4000m;
No conductive dust and corrosive gas place.
6. System panel functions
6.1 System panel Schematic drawing
