5 Installation.
5.1 Necessary tools.
See Fig. 8.
Fig. 8
5.2 Storage features and conditions.
The product must be stored in a dry place, protected from weather.
5.3 Transport.
Handle the product with care to avoid damages.
5.4 Handling.
Be really careful when moving the product (full of filter media, sand) because it is very heavy.
5.5 Positioning.
The product must be positioned under head.
The product must be placed in an area not subject to flooding.
The product cannot be used on the water surface.
The product must always be located at least 3.5 [m] from the edge of the swimming pool from which
water is drawn (Fig. 9).
Fig. 9
It is advisable to take the following into account:
• Dimensions and position of hydraulic parts.
• Necessary clearance.
• Supply cord position (pump).
• Location of the power supply (power outlet).
• Support and its location.
• The product must be accessible after installation.
OUTIN
WASTE
2
3
1
3 2
3
.
5
[
m
]
OUTIN
WASTE
2 3
1
3 2
3
.
5
[
m
]
V4
V6
4
4
4
4
OUT
IN
WASTE
2 3
1
3
2
V7
4
4
3
.
5
[
m
]
