page 12Showerbuddy SB3T
To adjust the seat height remove the
securing clips and slide the height
adjustment tubes up or down to the
required height.
Secure both height adjustment tubes at
the required height using 1 large securing
clip on each base leg.
NOTE
- Each height adjustment hole raises the
seat base 1”.
-
Check to ensure all securing clips are
fully inserted.
- Ensure both height adjustment tubes are
aligned at the same height.
To attach the calf strap to the footrests
wrap the end of the calf strap around the
outside of the footrest. Connect the velcro
strip which is attached to the end of the
calf strap to the velcro strip in the centre.
Ensure the velcro strips are on the back
side of the calf strap.
Repeat this process to attach the other
side of the calf strap to the footrest.
