ShowerLux LINEA TOUCH - Pivot Contents & Equipment; Bag 1 & Bag 2 Components; Seals Components; Required Equipment

2
62158
Glass squeegee ...... x 1
● Crosshead screwdriver ● Drill ● 8mm Masonry bit ● Hammer●Rubber mallet ● Tape measure ● Pencil
●Fine tooth saw● Spirit level ● Masking tape ● Silicone sealant / Applicator ● De-greaser e.g White spirit
EQUIPMENT NEEDED
Issue 1 - 07/11
PIVOT CONTENTS
BAG 3.1
SEALS
60140
9.5mm Screw .......... x 8
L
60005
13mm Screw ........... x 2
M
62064
65mm Screw ........... x 8
N
25006
Wall plug .................. x 8
O
62092
Centre punch .......... x 1
P
62072
2.8mm Drill bit
......... x 1
Q
20795
Screw cover ............ x 8
R
Frame cap ............ x 1/1
S
T&J
V
24828
Measuring
tool ............ x 1
W
2361
Horizontal seal ....... x 2
Z5
2211 (L)
2212 (R)
2210
Wall channel cap .... x 2
2550
Pivot Block
Screw Cover Cap ...... x 2
A
2292
Screw Hole Plug ..... x 8
B
BAG 2
BAG 1
62428
3mm Allen key ........ x 1
U
24828
Linea Touch
Handle....... x 1
I
Glide Handle....... x 1
I
