6
Issue 1 - 07/11
From the inside of the shower enclosure, silicone the entire
vertical length of the wall channels up against the walls.
Important: Do not silicone the lower horizontal frame of the
enclosure on the inside or the ends of the vertical profiles
of the frame.
STEP 12
Inside
10cm
From outside the enclosure, silicone along the bottom of the
enclosure on the shower tray all the way around and 10cm
up each wall.
Also silicone 10cm up the joint between the wall channel and
side profiles as shown.
STEP 13
STEP 11
Place the correctly handed frame caps (T & J) as shown and
fix using 13mm countersunk screws (M).
Push-fit all eight screw hole plugs (B) as shown.
MM
J
T
B
10cm
B
