Showtec LAMPY Series
Product: 50740 / 50741 / 50742 / 50743
4.2. Back View
The Back panel of the LAMPY20 and LAMPY40 are identical in terms of connectors.
Please make sure to connect any external Screen before booting up the console. The UI is at a fixed
resolution of 1920 x 1080 (Full HD), so please make sure your monitor supports the resolution.
The external screen may also be a touchscreen.
Fig. 8 LAMPY Back panel
1
Ethernet Port
6
DMX Outputs
2
USB 2.0 and 3.0 (blue) Ports
7
Audio Input
3
DVI Port
8
Midi Out / Thru / In
4
Power Button
5
Power Input (PowerCon)
