SHOWTEC LED Orbit I - DMX Protocol

9
DMX Protocol
Channel 1 – Strobe
0-7
Shutter open / Full beam
8-255
Strobe effect, from slow to fast (0-10 flashes/sec.)
Channel 2 – Red
0-255
Gradual adjustment Red from 0 – 100%
Channel 3 – Green
0-255
Gradual adjustment Green from 0 – 100%
Channel 4 – Blue
0-255
Gradual adjustment Blue from 0 – 100%
Channel 5 – Built-in Programs
0-255
Play one of the built-in color settings
Channel 6 – Speed
0-255
Gradual adjustment from color change speed
Channel 7 - Horizontal movement (Pan)
Push the slider up, in order to move head horizontally (PAN).
Gradual head adjustment from one end of the slider to the other (0-255, 128-center).
The head can be turned by 540° and stopped at any position you wish.
Channel 8 - Vertical movement (Tilt)
Push the slider, up in order to move head vertically (TILT).
Gradual head adjustment from one end of the slider to the other (0-255, 128-center).
The head can be turned by 280° and stopped at any position you wish.
Channel 9 - Pan fine 16 bit
Channel 10 - Tilt fine 16 bit
The LED Orbit I can be operated with a controller in control mode or without the controller in stand-alone
mode.
