Description of the device
Features
• 4 Channel dimmer / switchpack
• Max 1449 Watt per Channel (6.3A per channel max)
• Max Load 3680 Watt (at 230V)
• 4 Shuko outputs
Overview
Fig. 1
1 2 3 4 5 6 7 8 9 10 11
1) Channel Faders 7) Power ON/OFF
2) Mode Button 8) Power 230V
3) Menu Button 9) Channels Fuses 6.3A 250V
4) UP Button 10) DMX IN
5) Down Button 11) DMX OUT
6) 4x Schuck Outputs
Installation
Remove all packing materials from the Multidim. Check that all foam and plastic padding is removed.
Connect all cables.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
