9
ENGLISH
WAX GUARD
You should place wax guards on the nozzle of your E2 earphones before using them. These
protective rings are found on an adhesive strip in the fit kit that comes with your earphones.
To place a wax guard on one of your E2 earphones:
1. Remove the sleeve from the earphone nozzle.
2. If there is a dirty wax guard on the earphone, peel it off.
3. Clean the tip of the E2 nozzle with an antiseptic or alcohol wipe.
4. Make sure that the tip of the nozzle is dry, then remove a wax guard from the supplied
strip and place it on the tip of the nozzle, adhesive side down.
5. Replace the sleeve on the earphone.
FIGURE 2: E2 Wax Guard Installation
WAX GUARD
NOZZLE
IMPORTANT: Do not place wax guards on sleeves! Wax guards are
intended for use on the tip of the earphone only. If wax guards are placed on
sleeves they will not function properly and may fall off the sleeves into your ears.
