Weight
10.9 oz (310 g)
Housing
PC/ABS
Spurious Rejection
> 35 dB, typical
Gain Adjustment Range
-20 to 40 dB, 1 dB increments
Phantom Power Protection
Yes
AUDIO OUTPUT:
Configuration
XLR Output Impedance balanced
6.35 mm (1/4") output Impedance balanced
Impedance
XLR Output 100 Ω
6.35 mm (1/4") output 100 Ω (50 Ω, Unbalanced)
Maximum Audio Output Level
XLR connector +1 dBV
6.35 mm (1/4") connector +8.5 dBV
Pin Assignments
XLR Output 1=ground, 2=hot, 3=cold
6.35 mm (1/4") connector Tip=audio, Ring=no audio, Sleeve=ground
RECEIVER ANTENNA INPUT:
Impedance
50 Ω
Maximum Input Level
-20 dBm
GLXD1+
Power Requirements
Shure Rechargeable Li-Ion Battery SB904
USB Power Supply (US/Canada) SBC10-USB15WSUSTWJ
