Shure U1/U1L Body-Pack UHF Transmitter
25C1021 (BG)24
Replacement Parts and Drawings
Table 5
Printed Circuit Board Replacement Parts:
Side 2
Reference
Designation
Description
Shure Part
Number
Non-SMT Components
D102 LED, green 86C8419
J2 Receptacle, TINI QG, 4-pin, male: U1 ONLY 95A8413
J103 Receptacle, LEMO, OS: U1L ONLY 95A8601
S103 Switch, toggle, DPDT 55A189
SMT Components
D101,103 Rectifier, Schottky, MBRS140 184A16
D201,202 Diode, dual 184A08
J104 Receptacle 170A08
L200,205,208, 211 Inductor 10%, 0.18 µH 162R10
Q102 Transistor, MOS FET, MDT3055EL 183A35
Q103,202,204 Transistor, NPN SOT-23, MMBT5089L 183A38
Q207,209 Transistor, PNP SOT-23, MMBT5087 183A01
Q208 Transistor, Dual Gate Ga As MESFET, NE25139 183C12
SW201 Switch, 3-position 155A09
U102 Comparator 188A136
U105 Integrated Circuit, 5 V dc/dc converter,
MAX751CSA
188A182
U106 Voltage detector 188B210
U208 Dual operational amplifier 188A118
