Shure UR1M - Page 4

Shure Incorporated
4/7
Overall Dimensions 47,5 mm L x 63 mm W x 17 mm D (1.9 x 2.5 x 0.67 in)
Net Weight 64 g (2.3 oz.) without batteries
Wiring
TA4F Connector
NOTE: LAVALIER MIC TIES PINS 3 AND 4 TOGETHER—GUITAR CABLE DOES NOT.
Lemo Connector
UR1M Transmitter Information
UR1M Transmitter RF Output:
Connector: SMA
Actual Impedance: 50
Pin Assignments: Shell = Ground
Center = Signal
