Shuttle XPC - Page 17

Shuttle
®
XPC Barebone SZ68R5
Premium PC platform with
complete CPU compatibility
and SRT (SSD caching)
LGA1155 socket for all 22 nm / 32 nm processors
 Supports the second and third* generation of Intel Core
processors (i3/i5/i7)
Up to 32 GB of DDR3 RAM
 Four DIMM sockets with dual-channel functionality
Powerful CPU-integrated Intel HD graphics function***
 HDMI and DVI-I output support full HD as well as Blu-ray video
playback for solid 3D performance
Smart USB for charging iPhone/iPad
 A USB port on the front with 2 Amp power feed is suitable
for devices with high charging or quick-charge requirements
Optional accessories: PHD3, H-RS232
SZ68R5
Speed Functionality Energy Efficiency Space Saving Price
•••
••• •• • ••
Shuttle
®
XPC Barebone SX58H7 Pro
Mini-PC for Intel 6-core processors
and high-end graphics cards
LGA1366 socket for high-end Intel Core i7 processors
 e.g. Intel Core i7-990X Extreme Edition processor,
(6 cores, 12 MB cache, 3.46 GHz, 6.40 GT/s Intel QPI)
Up to 16 GB of DDR3 RAM
 Four DIMM sockets, supports triple-channel mode
Supports the biggest dual-slot graphics cards**
 2x PCIe-x16-2.0 for two single-slot graphics cards
or one large dual-slot graphics card
 500W power supply with additional 6+8-pin power supply
Dual Gigabit-LAN
 Two interfaces in teaming mode, failure protection
or have one PC connected to two different networks
Optional accessories: PHD3
SX58H7 Pro
Speed Functionality Energy Efficiency Space Saving Price
•••
•• • • •••
***The integrated video outputs cannot be used,if the processor installed does not have an integrated
graphics function such as Intel Core i5-2380P, Core i5-2450P and Core i5-2550K. 17
*from BIOS version .201
**Supports e.g. NVIDIA GeForce GTX 580, NVIDIA Quadro 5000 or AMD Radeon HD 6970.
Please also note compatibility list and dimensions!
