Mini PC
24
Category Basic Home-Media Performance
Model SH61R4 SH67H3 / SH67H7 SX58H7 Pro
Colour
Black Black Black
Complete system with Windows
R4 6100B, R4 6100BA H3 6700H H7 5820P
Processor
Socket
LGA1155 LGA1155 LGA1366
Support
Intel Core i3/i5/i7, Pentium, Celeron,
TDP max. 95 W
Intel Core i3/i5/i7, Pentium, Celeron,
TDP max. 95 W
Intel Core i7, Quad- and Hexa-Core
Cooling
I.C.E. Heatpipe I.C.E. Heatpipe I.C.E. Heatpipe
Memory
2x 240 pin DIMM-slots, maximum 2x 8 GB DDR3-1333
Dual channel
4x 240 pin DIMM-slots, maximum 4x 8 GB DDR3-1333
Dual channel
4x 240 pin DIMM-slots, maximum 4x 4 GB DDR3-1333
Triple channel (3+1)
Chipset
Northbridge
(integrated in CPU) (integrated in CPU) Intel X58 Express
Southbridge
Intel H61 Express Intel H67 Express Intel ICH10R (RAID)
Audio
IDT 92HD89C (5.1 ch) Realtek ALC888 (7.1 ch) Realtek ALC888S (7.1 ch)
Network
Realtek RTL 8111E (Gigabit), supports WOL and PXE Realtek RTL 8111E (Gigabit), supports WOL and PXE 2xRealtek 8111E (Gigabit), supports WOL,PXE,Teaming
Integrated graphics function
Intel GMA HD in CPU, UMA max. 1.692 MB*,
supports two displays**
Intel GMA HD in CPU, UMA max. 1.692 MB*,
supports two displays**
–
Slots
Graphics card
1x PCI-Express-x16-2.0, supports dual-slot graphics
cards, 6-pin power connection
1x PCI-Express-x16-2.0, supports dual-slot graphics
cards, 6-pin power connection
2x PCI-Express-16-2.0, supports 2x single-slot or 1x
dual-slot graphics card, 6+8-pin power connector,
ATI CrossFire, NVIDIA SLI support
PCI
1x PCI-Express-x1-2.0, 1x Mini-PCI-Express-x1-2.0 1x PCI-Express-x1-2.0, 1x Mini-PCI-Express-x1-2.0 1x Mini-PCIe-x1-2.0
Ports,LEDs
and buttons
Front
Microphone input, headphones output, 2x USB 2.0,
Power LED, hard disk LED, On/Off button
Microphone input, headphones output, 2x USB 3.0,
eSATA/USB 2.0 Combo,
Power LED, hard disk LED, On/Off button, Reset button
Microphone input, headphones output, 2x USB 3.0,
eSATA/USB 2.0 Combo, power LED, hard disk LED,
On/Off button, Reset button
Rear
DVI-D, DVI-I (digital and analog), 2x USB 3.0 and 6x
USB 2.0, Gigabit-LAN, Line-out, Line-in, Microphone,
Clear CMOS button, opening for Kensington-Lock
HDMI (with Digital Audio), DVI-I (digital and analog),
2x USB 3.0 and 4x USB 2.0, eSATA, Gigabit-LAN, Audio
8-channel Line-out, Line-in, Optical S/PDIF output,
Clear CMOS button
8x USB 2.0, 2x Gigabit-LAN, eSATA + power supply,
Audio 8-channel Line-out, Audio Line-in, Optical
S/PDIF output, Clear CMOS button
Onboard
4x SATA 3 Gbit/s, serial port (RS-232)
2x SATA 6 Gbit/s, 2x SATA 3 Gbit/s, 2x USB 2.0, serial port
(RS-232)
2x SATA 6 Gbit/s, 2x SATA 3 Gbit/s, 2x USB 2.0
Drive bays and
supported drives
1x 5.25" (for optical drive), 2x 3.5" internal (e.g. for
hard disk, SSD)
1x 5.25" (for optical drive), 2x 3.5" internal + external
(e.g. for hard disk, SSD,
card reader), supports RAID 0, 1, 5, 10
1x 5.25" (for ODD), 2x 3.5" internal + external (e.g. for
HDD, SSD, card reader), supports RAID 0, 1
Power supply
250W standard power supply,
Input: 100-240 V AC 50/60 Hz
300W 80 PLUS Bronze,
Input: 100-240 V AC 50/60 Hz
500W 80 PLUS Bronze,
Input: 100-240 V AC 50/60 Hz
BIOS
AMI BIOS, supports ACPI 3.0 and UEFI AMI BIOS, supports ACPI 3.0 and UEFI AMI BIOS supports ACPI 3.0 and UEFI
Material
Aluminium Aluminium Aluminium
Dimensions and weight
32.5 x 21.5 x 19 cm (DWH) = 13.3 L, 3.2 kg 32.5 x 20.8 x 19.6 cm (DWH) = 12.8 L, 3.2 kg 32.5 x 20.8 x 19,6 cm (DWH) = 12.8 L, 4.2 kg
Permitted ambient parameters
Operating temperature: 0-35°C, Air humidity: 10-90% Operating temperature: 0-35°C, Air humidity: 10-90% Operating temperature: 0-35 °C, Air humidity: 10-90 %
Optional accessories
2.5" HDD/SSD installation frame (PHD3),
COM port (H-RS232), 300W power supply unit
(PC61J), 500W power supply unit (PC63J)
2.5" HDD/SSD installation frame (PHD3),
COM port (H-RS232), 500W power supply unit (PC63)
2.5" HDD/SSD mounting frame (PHD3)
