Shuttle XPC - PnP;PCI Configurations

All-in-One PC
28
Category
Basic Basic Home-Media
Model
X50V2 Plus X50V3L* X70S
Colour
Black or white Black or white Black
Complete system with Windows
X 5020T Plus, X 5020TA Plus X 5031T, X 5031TA X 7000T, X 7000TA
Processor
Model
Intel Atom D525 Intel Atom D2550
Intel Core i3/i5/i7, Pentium, Celeron
(LGA1155, TDP max. 65 W)
Clock speed
2x 1.8 GHz, 4 Threads 2x 1.86 GHz, 4 Threads (dependant on processor)
Cooling
Passive, fanless Passive, fanless I.C.E. Heatpipe
Memory
2x 204-Pin SO-DIMM slots, maximum 2x 2 GB DDR3-800
2x 204-Pin SO-DIMM slots, maximum 2x 2 GB DDR3-
1066
2x 204-Pin SO-DIMM slots, maximum 2x 8 GB
DDR3-1600
Chipset
Northbridge
(integrated in CPU) (integrated in CPU) (integrated in processor)
Southbridge
Intel NM10 Intel NM10 Intel H61 Express
Audio
IDT 92HD81 IDT 92HD87 Realtek ALC269
Network
JMC261 (100 Mbit) supports WOL Realtek RTL8411 (Gigabit) supports WOL 2x Realtek 8111E (Gigabit) supports WOL and PXE
Wireless network, WLAN
802.11b/g/n, 150 Mbit 802.11b/g/n, 150 Mbit 802.11b/g/n, 300 Mbit
Integrated graphics function
Intel GMA 3150, UMA max. 265 MB,
supports dual monitoring
Intel GMA 3650, UMA max. 384 MB,
supports dual monitoring
Intel GMA HD integrated in processor,
UMA max. 1.692 MB, supports dual monitoring
Screen
Resolution
39.6 cm/ 15.6" LCD display, LED backlight,
16:9 widescreen resolution: 1.366 x 768
39.6 cm/ 15.6" LCD display, LED backlight,
16:9 widescreen resolution: 1.366 x 768
46,7 cm/ 18,5" LCD display, LED backlight,
16:9 widescreen resolution: 1.366 x 768
Touchscreen
Resistive Resistive Resistive
Communication
Webcam
2.0 Megapixels (1.600 x 1.200) 2.0 Megapixels (1.600 x 1.200) 2,0 Megapixel (1.600 x 1.200)
Loudspeakers
and microphone
2x 2 W loudspeaker, capacitor microphone 2x 2 W loudspeaker, capacitor microphone 2x 2 W loudspeaker, capacitor microphone
Ports,LEDs
and buttons
Front
Power LED, hard disk LED, WLAN LED Power LED, hard disk LED, WLAN LED Power LED, hard disk LED
Rear
VGA, (Option: 2x RS-232, 1x LPT)
HDMI (with Digital Audio), VGA, (Option: 2x RS-232,
1x LPT)
HDMI (with Digital Audio), Microphone input, head-
phones output, 2x USB 3.0, 2x USB 2.0, 1x RS-232,
2x LAN, power supply, (Option: 2x RS-232, 1x LPT)
Side
Microphone input, headphones output, 4x USB 2.0,
network, power supply, On/Off button
Microphone input, headphones output, 4x USB 2.0,
network, power supply, On/Off button
4x USB 2.0,
On/Off button
Drive bays and
supported drives
Drive bays: 1x 2.5", supports 1x 2.5" hard disk internal
ports: 1x SATA 3 Gbit/s, card reader: SD, SDHC & SDXC
Drive bays: 1x 2.5", supports 1x 2.5" hard disk, internal
ports: 1x SATA 3 Gbit/s, card reader: SD, SDHC & SDXC
Drive bays: 1x 2,5", supports 1x 2,5" hard disk/SSD, inter-
nal ports: 2x SATA3Gbit/s,cardreader:SD,SDHC,SDXC
Power supply
External 40 W power supply, output: 19 V DC,
input: 100-240 V AC
External 40 W power supply, output: 19 V DC,
input: 100-240 V AC
External 120 W power supply, output: 19 V DC,
input: 100-240 V AC
BIOS
AMI BIOS supports ACPI 3.0 AMI BIOS supports ACPI 3.0 AMI BIOS supports ACPI 2.0 and UEFI
Dimensions
39.13 x 32.7 x 3.6 cm (DWH), 2.93 kg 39.13 x 32.7 x 4.2 cm (DWH), 2.93 kg 46.8 x 36.4 x 5.7 cm (DWH), 4.6 kg
Permitted ambient parameters
Operating temperature: 0-35 °C, Air humidity: 10-90 % Operating temperature: 0-35 °C, Air humidity: 10-90 % Operating temperature: 0-40 °C, Air humidity: 10-90 %
Optional accessories
IO expansion 2x COM + 1x LPT (PCL68),
carrying bag (PF55)
IO expansion 2x COM + 1x LPT (PCL69),
carrying bag (PF55)
IO expansion 2x COM + 1x LPT
