Figure 3
Figure 2
BLACK: Power Ground
RED: +12/24 VDC IN
BLUE: LIGHTS On/Off
WHITE: NMEA 0183 out
Not used
MALE
To Temperature probe
I
MALE FEMALE
To Temperature probe
BLACK: Power Ground
RED: +12/24 VDC IN
BLUE: LIGHTS On/Off
WHITE: NMEA 0183 out
