512.832.6939 І screeninnovations.com
NOTE: This unit is suitable for outdoor use in damp locations. Do not expose to rain or immerse in water.
Install at least 3ft. above ground level with the receptacle pointed down. When used outdoors, plug the
unit into a GFCI outlet with a receptacle cover rated for outdoor use.
NOTE: Plug directly into outlet. Do not use
with extension cords.
3. The manual/program button on the outdoor
switch allows the user to: Turn the connected
equipment ON/OFF. If the outdoor switch is
OFF, press the button once to turn it ON and
vice versa to turn OFF.
1. Two mounting tabs with screw keyholes are
located at the top of this unit. Install the
included screw in the desired location leaving
3/16in. of the screw exposed.
2. Align the mounting tab with the screw head,
slide the tab over the screw and let the unit
drop to lock it in place.
Pg 2
Basic operation
The connected device can be turned ON/OFF in two
ways:
1. Manually from the front panel of the switch.
2. Remotely with a Zigbee controller.
Manual control
The manual/program button allows the user to
Turn ON/OFF the connected fixture.
Smart Outdoor Plug - Installation Instructions
Wiring Installation instructions
v. 1.0 І October 8, 2020
