SI Smart Outdoor Plug - Example System Drawing; Ideal Zigbee 3.0 Topology

Example System Drawing (Ideal Zigbee 3.0 topology)
7 m
1st hop2nd hop
7 m
Doc. # 400138
v. 1.0 І October 8, 2020
Smart Outdoor Plug - Installation Instructions
Pg 5
NOTE: Each Zigbee node should be within 7m of each other and a maxi-
mum of 7 hops from any end point to a mesh controller.
