SiAECOSYS VOTOL EM100 User Manual

SiAECOSYS V2
16
3.1.3、Motor type：Fill in according to the motor manufacturer parameters.
Note: Wheel Hub motor is surface mount
3.1.4、Hall, phase line exchange: exchange the motor forward and reverse.
3.2、The controller to speedometer date output has 2 types: Single-line speedometer and hall speedometer,
it needs to be decided by the vehicle’s speedometer.
3.3、Moving assist and cruising function：Used in two-wheelers
Note: Speed "3KM / H, torque 9 ~ 19N.M
3.4 Cruise function: function selection, the default does not open.
3.5 Dual voltage setting: default single voltage。
Note: The dual voltage function speed parameter value is followed by the motor speed setting. Adjust the
parameters on the setup page 2.
3.6 、 Reversing speed limit: The calculation formula is adjusted with reference to the EM_V3 parameter
adjustment calculation formula file.
Note: The speed of the two-wheeler is 5KM/H, and the tricycle is 15KM/H.
3.7、Reversing, EBS setting, low brake selection, starting safety switch function。
3.7.1、According to the weight of the vehicle (recommended within 30%)
3.7.2、Two-wheeler 35~60 interval
3.7.3、Two-wheeler 45~75 section
3.7.4、Energy recovery with lithium battery parameter value equipment, the actual road test shall prevail.
BMS protection results in burning MOS. Jianyi rushing discharge branch.
3.8、Low brake enable: brake signal high and low brake, default high brake, check low brake.
3.9、Safety Switch Function valid checked
3.10、Import configuration files: configured files are imported from the computer
3.11、Save configuration file
Standard Edition：BZB/V39
IO / V13 interface of IO version
CAN-CAN/V1
