DIMENSIONS
1 Connection for cylinder opening
Top column
6 Exit
2 Connection for cylinder closure
Top column
7 Connection top column
3 Connection for cylinder opening
bottom column
8 Connection bottom column
4 Connection for cylinder closure
bottom column
9 Connection for suction Ø 1”
5 Entry 10 Connection for male drain Ø ISO 40
11 Connection for pilot timer control
364-A 1” ½ GAS
364-B 2” GAS
364-C 2” ½ GAS
364-D 3” GAS
364-E01 ISO 50 GLUED
364-F01 ISO 63 GLUED
364-G01 ISO 75 GLUED
364-N01
Ø 60.4 GLUED
364-P01 3” NPT GLUED
