5. Specifications
Operating Voltage 9-28V DC
User Capacity 2000
Card Reading Distance 3-6 cm
Active Current ＜60mA
Idle Current 25±5 mA
Lock Output Load Max 3A
Alarm Output Load Max 20A
Operating Temperature -45℃～60℃
Operating Humidity 10%- 90% RH
Waterproof Conforms to IP68
Adjustable Door Relay time 0 -99 seconds
Adjustable Alarm Time 0- 3 minutes
Wiegand Interface Wiegand 26 bit
Wiring Connections Electric Lock, Exit Button, External Alarm
6. Installation
l Remove the back cover from the keypad using the supplied special screw driver
l Drill 2 holes on the wall for the Self tapping screws and I hole for the cable
l Put the supplied rubber bungs to into the two holes
l Fix the back cover firmly on the wall with 2 Self tapping screws
l Thread the cable through the cable hole
l Attach the keypad to the back cover.
