30 DST2600 User’s Manual
The signalling of a warning will end after its acknowledgment with the end of the causes which
generated it; the signalling of a block, which prevents the use of the genset, must be reset by
the operator by selecting the “OFF_RESET” mode with the arrows keys.
In “OFF_RESET” mode all the signalling are inhibited
Each anomaly signalling is composed by an alphanumerical code and by a message.
The alphanumerical code is composed by one character and by a three-digit number. The
character identifies the anomaly type with the following convention:
- Wxxx identifies a warning, an anomaly that doesn’t require the genset stopping
- Dxxx identifies a deactivation, an anomaly that requires the genset stopping with the
standard stop cycle
- Axxx identifies a block, an anomaly that immediately stops the genset
For some anomalies it is possible to configure their category; it is so possible to qualify them
as warning, block or deactivation.
Since the message for the configurable digital input can be customized and, moreover, some
written can be common to many anomalies (for example the written for the high coolant
temperature is the same for the contact sensor and the analogue sensor), what identifies
univocally an anomaly is its three-digit code. When reporting an anomaly, besides the
description, refer its correspondent number.
Here a summary of the DST2600 fundamental technical characteristics:
Mains
o Voltages measurements: L1-L2, L2-L3, L3-L1, mean value measurements
o Maximum phase-to-neutral voltage: < 300Vac cat. IV
o Frequency meter: resolution = 0.1 Hz.
Generator
o Voltages: L1-L2, L2-L3, L3-L1, true Root Means Square measurements
o Maximum phase-to-neutral voltage: < 300Vac cat. IV
o Currents: L1, L2, L3, true Root Means Square measurements
o Maximum nominal current: 58Aac
o Current overload measurement: up to 4 x Imax (with sinusoidal waveform)
o Frequency meter: resolution = 0.1 Hz.
Auxiliary (battery) supply voltage: 7,5…15 Vdc
Battery Voltage Measurement: resolution = 0.1V
Oil pressure measurements: VDO 0-10 Bar, VDO 0-5 Bar, VEGLIA 0-8 Bar
