DST2600 User’s Manual 31
Coolant temperature thermometer: VDO 120°, VDO 150°, VEGLIA, BERU
Fuel level sensor: VDO, VEGLIA
Maximum circuit breaker current:
o 2 interlocked contactors for load changeover: 4 poles, up to 63A AC1.
o Magnetic thermal automatic breaker (optional) for generator protection:
nominal 63A.
Operating temperature: -20 °C + 60 °C
Weight: 8.3 Kg with generator breaker
Overall dimensions: 460X345X140 mm (HxLxP) (P=165mm with emergency
pushbutton)
Protection degree: IP30
o With engine stopped and display light switched off: 150mA @ 12.6V
o With engine stopped and display light switched on: 320mA @12.6V
o With engine running: 440mA @ 12.5V
The current absorption from mains line is fundamentally function of the battery charge status.
Generally the mean absorption with engine stopped is about 110-130mAac @230Vac,
independently by the device working mode; with engine running and then with battery charger
alternator working the absorption is reduced practically to that of the active contactor (mains
or generator).
