Use and maintenance Manual AUTOMATIC GENSET CONTROL PANEL with GC310/GC350
STEEL SHEET BOX (80kVA)
Terminal
board
interface
Terminal
board
XM
Terminal
board
XA
Power cables
connection -
XR-MAINS
Power cables
connection -
XL-LOAD
Power cables
connection -
XG-GENSET
Earthing bar
Power zone
Auxiliaries
zone
