20
8 007 487/10-10-99 Technical Description • LGT © SICK AG • Safety Systems • Germany • All rights reserved
Fig. 27. Control unit dimensions LGTN
Fig. 28. Dimensional drawing of control unit for installation in a control cabinet
PG 11
Cable diameter 5 ... 12 mm
1 2 3 4 5 6 7 8 9 10 11 12
13 14
15 16 N L+
200
188
150
119
23
30 36
26,5
30
2324
75
SW 24
*)
*)
To receive cables Remove sleeve and prise apart
1 2 3 4 5 6 7 8 910 11 12
13 14
15 16 N L+
70
170
126
57
Push the side panels
outwards to remove
the cover.
26
*)
**)
Suitable for installation in a control cabinet.
Suitable for mounting on a support rail to EN 50022 (high or low DIN rail) or EN 50035 (slide rail).
**) for mounting on low DIN rail (20 mm)
**) for mounting on high DIN rail (28 mm)
