Fig. 107
6.25
6.20
6.45
6.48
8.16
6.47/
1FT506. - 6.31
6.45
Demontage von Tacho+ LG
Removing tachogenerator + pos. encoder
0.04 mm
8.970
8.971
Zwischenstecker
Socket adapter
6.20
8.972
8.16
8.960
Fig. 108
DIN933-M8x70-8.8
6.49
Demontage / Montage von Resolver
Removing / Fitting resolver
8.03
DIN913-
M6x20
DIN 913
Montage von Tacho + LG
Fitting tachogenerator + pos. encoder
15
DEUTSCH / ENGLISH
SW19
8.02
Stecker
Connector
