Serial Data Connector
Pin
Signal
Level
RCU Electronics
Input/Output
9
GND
10
DTR
3-9 V Configurable
Output
11
TXD
3-9 V Configurable
Output
12
RXD
3-9 V Configurable
Input
13
RI
3-9 V Configurable
Input
14
RI
RS232
Input
15
CTS
RS232
Input
16
RTS
RS232
Output
17
DSR
RS232
Input
18
Radio Power
Supply Positive
Configured
DC: 3-9 V or battery
Output
19
Radio Power
Supply Positive
Configured
DC: 3-9 V or battery
Output
20
PTT
Clean contact
Output
21
GND
22
Signal Supply
DC: 3-9 V 5 mA
Output
23
CTS
3-9 V Configurable
Input
24
RTS
3-9 V Configurable
Output
25
DCD
3-9 V Configurable
Input
10.5.5 3-9V Configurable Signals
Voltage range DC: 3-9 V configurable, only one voltage, called the signal supply is configured
for all these signals.
These signals supply an alternative data interface to RS232 to operate with radio/modems
which have logic level types of serial interface.
The signal supply itself is also available on pin 22.
Max output current for all lines is 10 mA.
10.5.6 RS232 Signals
Conforms to RS232 standard.
