Siemens 3ZX1012-0RV01-1AA1 - Product Dimensions and Mounting Clearances; Overall Product Dimensions; Mounting Hole Patterns and Clearances

Technische Änderungen vorbehalten. Zum späteren Gebrauch aufbewahren.
Subject to change without prior notice. Store for use at a later date.
© Siemens AG 1997
Bestell-Nr. / Order No.: 3ZX1012-0RV01-1AA1
Printed in the Federal Republic of Germany
> 9 mm
> 7 mm
20 mm
20 mm
90
70
94518
72
73,4
