Siemens A62 - Table of Contents

Company Confidential s Com
Copyright 2005© Siemens AG
Page 3 of 9
TI_Repair_L2.5l_A62_A65_A70_A75_R1.2.pdf Release 1.2
Table of Content
1 A62, A65, A70 & A75 board layout................................................................................................4
2 Connector SIM Card Reader .........................................................................................................5
3 Connector IO Jack.........................................................................................................................6
4 Connector Battery .........................................................................................................................7
5 Connector Display .........................................................................................................................8
6 LED_ KEYPAD_BACKLIGHT .......................................................................................................9
