1 A62, A65, A70 & A75 board layout
Jigs, Tools and Working materials for all described repairs:
- hot air blower
- soldering gun
- tweezers
- flux
- solder
Connector
SIM CARD READER
LED
Keypad Backlight
Connector
BATTERY
Connector
IO JACK
Connector
DISPLAY
