Getting started
Using the SIM card/battery
Your phone's display is delivered with a
protective film. Remove this film before get-
ting started. The service provider supplies
you with a SIM card on which all the im-
portant data for your account is stored. If
the SIM card is credit card-sized, snap out
the smaller segment and trim any rough
edges.
Remove the battery cover upwards
1
.
Insert SIM card
2
and push it fully into
the locating slot (make sure the angled
corner is in the correct position
3
). Then
push the retaining catch over the top of
the SIM card
4
.
Insert the battery sideways into the
phone
5
, then press downwards
6
until it engages.
To remove, press the retaining tab
7
then lift the battery out.
Insert the battery cover by the tabs at the
bottom
8
, then press downwards
9
,
until it engages.
Always switch off phone before removing
the battery!
Only 3-V SIM cards are supported. Please
contact your service provider if you have
an older card.
1
2
4
3
6
7
5
8
9
