Siemens Home and Office Communication Devices GmbH & Co. KG
Confidential 9 SHC CC RCT
Version 1.5 J. Junggebauer
Prepared power supplies
(1 wire opened for
current measurement)
Measurement of AC-adaptor current
Measurement of PSTN voltage
golden device base for
testing customer‘s handset
customer’s
system
Handset is
registered
to G4175
system or base station test
handset test
Connection for corded phones
under the bottom of G4175
golden device
handset for
testing
customer‘s
base station
Measurement
of carge
current
