Acuson Confidential
x Sequoia Service Training Manual P/N 59191 Rev. 1
PREFACE
Acuson is pleased to welcome you to the Sequoia® ultrasound
systems. The Sequoia systems are special-purpose machines
designed for general radiology, obstetrics, gynecology, cardiology,
and/or vascular exams.
Acuson systems have an exceptional record of dependability, and
Acuson has a customer service network ready to respond to the
needs of our customers.
For information on Acuson’s service offerings, please consult the
Acuson Service Provider or call us at 800-9-ACUSON or 650-969-
9112. For local numbers outside the United States, see the
Contacting Acuson heading in this section.
ABOUT THIS
MANUAL
The purpose of this manual is to familiarize service personnel with
basic operation, maintenance, and troubleshooting of Sequoia
systems. Service personnel are expected to be familiar with the use
of basic test equipment (DVM, oscilloscope, etc.) and with basic
ultrasound theory.
Use this manual when servicing a Sequoia ultrasound system.
KEY CONVENTIONS This manual uses several conventions to refer to controls on the
system. The following list shows the conventions and their
descriptions.
WARNING!
This manual is intended for use by trained service personnel. There are
lethal voltages inside Sequoia systems. Bodily harm, possibly death,
and damage to the system may result from untrained individuals
opening the system.
Symbol Description
[LEFT]
Represents a soft key
CALC
Represents a key, knob, switch, or toggle control
CODE + SIZE
Means “Press the CODE key and press SIZE”
◆
Indicates steps to follow to perform a procedure
NOTE: A Note indicates especially important information. It is not an alert to a
dangerous situation.
CAUTION! A Caution alerts the user to the potential for damage to the ultrasound
system or other equipment.
