Siemens AD2-P User Manual

Siemens Industry, Inc.
Building Technologies Division
9 P/N 315-049708-5
Figure 6 Typical Connections for the AD2-P / AD2-XHR Using FP-11 / FP-11C Detectors
NOTES: 1. The relay contacts are shown after a reset pulse, which represents the non-alarm condition. 2. The green grounding screw in the wiring compartment of the air duct housing is not used.
- +
DEVICE LOOP -
DEVICE LOOP +
NOT USED
OPTIONAL
REMOTE ALARM
INDICATOR MODEL
RLI-1 OR RLI-2
RED
REMOTE -
REMOTE +
NO
LOOP
DEVICE
++ --
NC
COM
NO
ALARM
RELAY
COM NC
COM
NC
NO
TO NEXT ADDRESSABLE DEVICE
- +
TB1
TB1
TB1
MODEL AD2-P
MODEL AD2-XHR
MODEL AD2-XHR
FP-11
FP-11C
LOOP WIRES. SEE COMPATIBLE CONTROL EQUIPMENT TABLE.
FP-11
FP-11C
FP-11
FP-11C
ALARM CONTACTS 125 VAC, 24 VDC, 2.5A SEE NOTE 1
ALARM CONTACTS 125 VAC, 24 VDC, 2.5A SEE NOTE 1
NO
LOOP
DEVICE
++ --
ALARM
RELAY
COM NC
NOT USED
If the relay contacts are being used to control 120 VAC operated equipment, ensure that the conduit is properly attached to the internal metal ground strap, using the proper conduit locking nuts. Failure to provide proper grounding may result in fatal electrical shock and violation of national and local codes.
